Electro Acoustic Specifications
- Power RMS 600 WATT
- Maximal Power 1200 WATT
- Nominal Diameter 12/315 MM
- Resonance(natural) Frequency 55 Hz
- Rated Impedance 8 OHM
- Sensitivity (1w/1m) 97 dB
- Frequency Response 55-4200 Hz
- Voice Coil Diameter 3"/75 MM
- Winding Material GP(Inside-Outside)
- Magnet 90 Oz
Thiele Small Parameters
- FS Hz 55 Hz
- Vas 49 mM
- Re Ohms 5.6 ohm
- Qms 7.5
- Qes 0.29
- Qts 0.28
- BL T/m 21 T/m
- MMS(grms) 72 Grams
- Xmax(mm) 4.75 mm
- Sd 55 mM
- Efficiency % 2.7 %
- EBP 190
- Nett Weight 7.91 KG
- Gross Weight 8.85 KG
- Packing Size 36*34*20 CM
- Power RMS 600 WATT
- Maximal Power 1200 WATT
- Nominal Diameter 12/315 MM
- Resonance(natural) Frequency 55 Hz
- Rated Impedance 8 OHM
- Sensitivity (1w/1m) 97 dB
- Frequency Response 55-4200 Hz
- Voice Coil Diameter 3"/75 MM
- Winding Material GP(Inside-Outside)
- Magnet 90 Oz
Thiele Small Parameters
- FS Hz 55 Hz
- Vas 49 mM
- Re Ohms 5.6 ohm
- Qms 7.5
- Qes 0.29
- Qts 0.28
- BL T/m 21 T/m
- MMS(grms) 72 Grams
- Xmax(mm) 4.75 mm
- Sd 55 mM
- Efficiency % 2.7 %
- EBP 190
- Nett Weight 7.91 KG
- Gross Weight 8.85 KG
- Packing Size 36*34*20 CM
