Electro Acoustic Specifications
- Power RMS 200 WATT
- Maximal Power 400 WATT
- Nominal Diameter 8/206 MM
- Resonance(natural) Frequency 230 Hz
- Rated Impedance 8 OHM
- Sensitivity (1w/1m) 96 dB
- Frequency Response 230-7000 Hz
- Voice Coil Diameter 2.5”/63 MM
- Winding Material CCAW
- Magnet 72 Oz
Thiele Small Parameters
- FS Hz 230 Hz
- Vas 1.5 mM
- Re Ohms 5.6 ohm
- Qms 17
- Qes 0.48
- Qts 0.47
- BL T/m 18 T/m
- MMS(grms) 21 Grams
- Xmax(mm) 3.15 mm
- Sd 21 mM
- Efficiency % 3 %
- EBP 479
- Nett Weight 5.73 KG
- Gross Weight 6.23 KG
- Packing Size 27*24*16 CM
- Power RMS 200 WATT
- Maximal Power 400 WATT
- Nominal Diameter 8/206 MM
- Resonance(natural) Frequency 230 Hz
- Rated Impedance 8 OHM
- Sensitivity (1w/1m) 96 dB
- Frequency Response 230-7000 Hz
- Voice Coil Diameter 2.5”/63 MM
- Winding Material CCAW
- Magnet 72 Oz
Thiele Small Parameters
- FS Hz 230 Hz
- Vas 1.5 mM
- Re Ohms 5.6 ohm
- Qms 17
- Qes 0.48
- Qts 0.47
- BL T/m 18 T/m
- MMS(grms) 21 Grams
- Xmax(mm) 3.15 mm
- Sd 21 mM
- Efficiency % 3 %
- EBP 479
- Nett Weight 5.73 KG
- Gross Weight 6.23 KG
- Packing Size 27*24*16 CM
